F930J476MBA

Name: F930J476MBA
Brand: Nichicon
SKU: F930J476MBA
Availability: InStock

Get $29 off orders over $999.

For orders over $2,999, get $160 off.

For orders over $6999, you will receive a $290 discount.

Manufacturer No:: F930J476MBA

Manufacturer:: Nichicon

Product Category:: Tantalum Capacitors

Description:: CAP TANT 47UF 6.3V 20% 1411

RoHs Status:: Lead Free / RoHS Compliant

Datasheet:: F930J476MBA Datasheet(PDF)

Get a quick quote? Send the BOM to [email protected]

Cut cost with low MOQ • Small orders shipped fast

Delivery Option:

Pay With Ease:

Inventory Quantity: 8,313

MOQ: 1

Submit the F930J476MBA inquiry form now or email us at [email protected], and we'll respond with pricing and lead time within 12 hours.

Purchase Instructions

Dyethin offers competitively priced F930J476MBA components, guaranteeing each component is 100% genuine and brand new, manufactured by Nichicon. To obtain a quote for the F930J476MBA, please complete the quick enquiry form on the right, specifying your required quantity and contact details. Our sales team will respond within 12 hours with pricing and delivery times.

Overview

The F930J476MBA is a solid tantalum electrolytic capacitor developed by Nichicon, featuring a molded chip structure with Case B dimensions. Rated at 6.3V with a capacitance of 47µF, it offers reliable surface-mount performance for compact electronic assemblies requiring stable filtering and decoupling capabilities. As part of the F93 series, it delivers balanced electrical characteristics and high temperature durability in standard consumer and industrial-grade designs.

Key Features

47µF capacitance with ±20% tolerance
Low ESR of 1.0Ω (100kHz)
Rated voltage: 6.3V, maximum surge voltage: 8V
Wide operating temperature range: –55°C to +125°C
Leakage current: ≤3.0µA at 20°C after 1 minute

Electrical Specifications

The F930J476MBA offers excellent performance consistency across thermal and electrical stress conditions. Dissipation factor is controlled at 6% (120Hz), and ESR is maintained at 1.0Ω at 100kHz. The component meets stringent reliability standards for capacitance change, leakage current, and loss factor under damp heat, temperature cycling, and reflow soldering heat resistance testing. Stability is preserved even under prolonged rated voltage application at 85°C and derated voltage at 125°C.

Applications

Consumer electronics (DC bias filtering, decoupling)
Automotive infotainment and accessory modules
Industrial embedded control units
Low-profile power modules and regulators
General-purpose surface-mount designs

Package & Reliability Information

F930J476MBA adopts a Case B molded resin package with a footprint of 3.5 mm × 2.8 mm and a height of 1.9 mm. Terminals are designed for reflow soldering, withstanding 260°C for up to 10 seconds without degradation. As illustrated in the above diagram, the capacitor maintains structural integrity under substrate bending conditions of 1 mm, ensuring resistance to mechanical stress in automated assembly. This robust packaging supports high-yield production and reliable end-use performance.

Below is a reference table of express delivery prices and timeframes:

Express Name	Prices within 0.5 kg	Statute of limitations (working days)
DHL	$28.00	3-5 days
FedEx	$30.00	4-6 days
EMS	$25.00	7-15 days
UPS	$30.00	3-6 days
TNT	$29.00	4-7 days

Price Note: The price is an example within 0.5Kg, the specific cost may be adjusted according to the actual weight and destination.
Timeliness Note: Timeliness is estimated time, excluding customs clearance delays or other uncontrollable factors.
Extra Charges: Remote surcharge may be incurred in some areas, subject to the quotation of the logistics company.

1. Can I buy the F930J476MBA online from Dyethin site?

Yes, you can buy, purchase, or order online the F930J476MBA directly through our website. We offer a secure checkout for fast and easy ordering.

2. Is the F930J476MBA currently in stock and ready to ship?
Absolutely! The F930J476MBA is in stock, available now, and ready to ship. We provide same-day shipping for all orders placed before our daily cutoff time.

3. Do you offer bulk pricing or wholesale discounts on the F930J476MBA?
Yes, we offer attractive bulk pricing, wholesale, and volume discounts on the F930J476MBA. For larger quantity orders, request an instant quote directly from our price list.

4. Do you provide F930J476MBA components through trusted supply networks?
We supply F930J476MBA voltage regulators from Nichicon through trusted global sourcing channels, ensuring consistent quality and performance.

5. Can I find technical specifications or a datasheet for the F930J476MBA?
Certainly! The complete technical specifications and datasheet for the F930J476MBA are readily available and clearly listed on our product page.

6. How competitive is your pricing for the F930J476MBA compared to other suppliers?
Our pricing on the F930J476MBA is highly competitive, cost-effective, and consistently reviewed to ensure you get excellent value for your purchase.

7. Can I get fast delivery or bulk purchase discounts when buying F930J476MBA components?
Yes, we offer flexible fast delivery, competitive bulk pricing, and attractive discounts for larger purchase quantities. Contact us directly for your bulk purchasing requirements.

Specifications

Product Category :

Tantalum Capacitors

Manufacturer :

Nichicon

Product type :

Capacitors

Capacitance :

47µF

ESR (Equivalent Series Resistance) :

1 Ohm

Failure Rate :

Features :

General Purpose

Height - Seated (Max) :

0.083" (2.10mm)

Lead Spacing :

Lifetime @ Temp. :

Manufacturer Size Code :

Mounting Type :

Surface Mount

Operating Temperature :

-55°C ~ 125°C

Package / Case :

1411 (3528 Metric)

Packaging :

Digi-Reel®

Part Status :

Discontinued at Digi-Key

Ratings :

Series :

F93

Size / Dimension :

0.138" L x 0.110" W (3.50mm x 2.80mm)

Tolerance :

±20%

Type :

Molded

Voltage - Rated :

6.3V
